醫用內窺鏡系統主要由設備系統與手術器械系統組成。手術器械系統主要按科室或手術名稱來分類。有各科使用的內窺鏡、專用器械、配合設備使用的手術器械和一次性手術耗材。這里就不詳細介紹了,下面內窺鏡維修公司來講一下設備系統的結構組成。

The medical endoscope system mainly consists of equipment system and surgical instrument system. The surgical instrument system is mainly classified by department or surgical name. There are endoscopes, specialized instruments, surgical instruments used in conjunction with equipment, and disposable surgical consumables used in various departments. I won't go into detail here. Below, the endoscope maintenance company will explain the structural composition of the equipment system.

在設備系統中我們通常可以分為：攝像顯像系統，影像記錄系統，光源系統，人工氣腹系統，液體加壓系統，電凝電切系統，動力消融系統，沖洗吸引系統等等。

In equipment systems, we can usually be divided into: camera imaging systems, image recording systems, light source systems, artificial pneumoperitoneum systems, liquid pressurization systems, electrocoagulation and electrocautery systems, dynamic ablation systems, flushing and suction systems, and so on.

(1)攝像顯像系統：該系統包括顯示器和攝像機。顯示器有常規的CRT和液晶兩種，攝像機有單CCD和3CCD兩種。現在高端的使用客戶多是液晶顯示器配3CCD攝像器。

(1) Camera and imaging system: This system includes a display and a camera. There are two types of monitors: conventional CRT and LCD, and two types of cameras: single CCD and 3CCD. Nowadays, high-end customers mostly use LCD monitors with 3CCD cameras.

(2)影像記錄系統：現在很多醫院都選擇以電腦為基礎的圖文工作站。該系統分兩部分：電腦硬件和圖文采集軟件。

(2) Image recording system: Nowadays, many hospitals choose computer-based image and text workstations. The system is divided into two parts: computer hardware and image and text acquisition software.

(3)源系統：又稱冷光源。冷光源燈泡中充有鹵素和氙氣兩種，其輸出功率為70-400W。現在300W氙光源是主流的產品。其突出特點是光線強烈，色溫5600-6000k，與太陽光類似，涵蓋了從紫外線到紅外線的整個波段。

(3) Source system: also known as cold light source. The cold light bulb is filled with halogen and xenon gas, with an output power of 70-400W. The 300W xenon light source is now the mainstream product. Its prominent feature is strong light, with a color temperature of 5600-6000k, similar to sunlight, covering the entire spectrum from ultraviolet to infrared.

(4)人工氣腹系統：將氣腹機與二氧化碳鋼瓶連接好，并旋開鋼瓶上的閥門，然后開啟氣腹機，根據手術的需要，選擇壓力預設值，當腹腔內壓力超過或低于設定值時，全自動二氧化碳氣腹機可自動開始或停止注氣。

(4) Artificial pneumoperitoneum system: Connect the pneumoperitoneum machine to a carbon dioxide cylinder, unscrew the valve on the cylinder, and then turn on the pneumoperitoneum machine. According to the surgical needs, select a preset pressure value. When the abdominal pressure exceeds or falls below the set value, the fully automatic carbon dioxide pneumoperitoneum machine can automatically start or stop gas injection.

醫用內窺鏡系統的組成事項就講解到這里了，希望能夠給您好的幫助，更多事項就來我們網站http://www.cnxgtzyj.cn咨詢！

That's all for the composition of the medical endoscope system. We hope it can be helpful to you. For more information, please come to our website http://www.cnxgtzyj.cn consulting service
